2/3 inch 5 Mega Pixel Camera Compatible Fixed Focal Lens
● AR multiband coat
Improvement of transmittance in a wide wavelength range from the visible light region to the near infrared light region
● Iris click mechanism
The click mechanism which can easily adjust the aperture position is carried.
● W locking mechanism
Focus and iris can be firmly fixed, and vibration resistance is strengthened.
Also, in order to avoid interference, locking hole mounting holes can be selected from 3 locations (120 ° interval).
| Model | Format | Mount | Focal length | F no. | M.O.D | Size | Mass | |
|---|---|---|---|---|---|---|---|---|
| JHF8M-5MP | 2/3 | C | 8 | F2.8 | 0.1m | φ54×50.3mm | 200g | DL |
| JHF12M-5MP | 2/3 | C | 12 | F1.8 | 0.15m | φ57×58mm | 240g | DL |
| JHF16M-5MP | 2/3 | C | 16 | F1.4 | 0.2m | φ40×51.5mm | 240g | DL |
| JHF25M-5MP | 2/3 | C | 25 | F1.4 | 0.2m | φ40×42mm | 180g | DL |
| JHF35M-5MP | 2/3 | C | 35 | F1.4 | 0.25m | φ40×42.5mm | 230g | DL |
